Premium Lever Hoists by Sumner offer advanced features and higher performance. Capacities range from 0.8 to 9 tons across multiple models. The hoists use a single fused brake design for smooth operation. Zinc phosphate chains provide high resistance to corrosion. No preload is required before operation, making them user-friendly. The hard steel sheave rollers ensure load security under stress. Each unit is tested to 1.5x safety factors and meets all relevant standards. Removable top hooks allow for flexible anchoring. Chain fall lengths range from 5 to 20 feet. These hoists are built for demanding lifting tasks in harsh environments.
Premium Lever Hoists
Mobile Nav
Specifications
| .8T LVR HST 15′ PLH080C15 | 787482 | 113″ (2870.2 mm) | 158″ (4013.2 mm) | 4.685″ (119.0 mm) | 12.787 lb (5.80 kg) |
| .8T LVR HST 20′ PLH080C20 | 787483 | 113″ (2870.2 mm) | 158″ (4013.2 mm) | 4.685″ (119.0 mm) | 12.787 lb (5.80 kg) |
| .8T LVR HST 5′ PLH080C05 | 787480 | 113″ (2870.2 mm) | 158″ (4013.2 mm) | 4.685″ (119.0 mm) | 12.787 lb (5.80 kg) |
| 1.6T LVR HST 10′ PLH160C10 | 787489 | 128″ (3251.2 mm) | 174″ (4419.6 mm) | 4.961″ (126.0 mm) | 17.857 lb (8.10 kg) |
| 1.6T LVR HST 20′ PLH160C20 | 787491 | 128″ (3251.2 mm) | 174″ (4419.6 mm) | 4.961″ (126.0 mm) | 17.857 lb (8.10 kg) |
| 1.6T LVR HST 5′ PLH160C05 | 787488 | 128″ (3251.2 mm) | 174″ (4419.6 mm) | 4.961″ (126.0 mm) | 17.857 lb (8.10 kg) |
| 1T LVR HST 10′ PLH100C10 | 787485 | 113″ (2870.2 mm) | 158″ (4013.2 mm) | 4.685″ (119.0 mm) | 13.228 lb (6.00 kg) |
| 1T LVR HST 15′ PLH100C15 | 787486 | 113″ (2870.2 mm) | 158″ (4013.2 mm) | 4.685″ (119.0 mm) | 13.228 lb (6.00 kg) |
| 1T LVR HST 20′ PLH100C20 | 787487 | 113″ (2870.2 mm) | 158″ (4013.2 mm) | 4.685″ (119.0 mm) | 13.228 lb (6.00 kg) |
| 1T LVR HST 5′ PLH100C05 | 787484 | 113″ (2870.2 mm) | 158″ (4013.2 mm) | 4.685″ (119.0 mm) | 13.228 lb (6.00 kg) |
| 2.5T LVR HST 10′ LFT&OLP PLH250C10WO | 787521 | ||||
| 2.5T LVR HST 10′ PLH250C10 | 787493 | ||||
| 2.5T LVR HST 10′ PLH250C10 | 787493 | ||||
| 2.5T LVR HST 15′ PLH250C15 | 787494 | ||||
| 2.5T LVR HST 20′ PLH250C20 | 787495 | ||||
| 2.5T LVR HST 5′ PLH250C05 | 787492 | ||||
| 3.2T LVR HST 15′ PLH320C15 | 787498 | 185″ (4699.0 mm) | 225″ (5715.0 mm) | 6.260″ (159.0 mm) | 29.321 lb (13.30 kg) |
| 3.2T LVR HST 20′ PLH320C20 | 787499 | 185″ (4699.0 mm) | 225″ (5715.0 mm) | 6.260″ (159.0 mm) | 29.321 lb (13.30 kg) |
| 6.3T LVR HST 10′ PLH630C10 | 787501 | 220″ (5588.0 mm) | 235″ (5969.0 mm) | 8.583″ (218.0 mm) | 56.218 lb (25.50 kg) |
| 6.3T LVR HST 15′ PLH630C15 | 787502 | 220″ (5588.0 mm) | 235″ (5969.0 mm) | 8.583″ (218.0 mm) | 56.218 lb (25.50 kg) |
| 6.3T LVR HST 5′ PLH630C05 | 787500 | 220″ (5588.0 mm) | 235″ (5969.0 mm) | 8.583″ (218.0 mm) | 56.218 lb (25.50 kg) |
Features & Benefits
- Fused Brake Design
- 360 Degree Alloy Steel hooks
- Complies with ANSI/ASME and OSHA Standards
- Unique Zink phosphate chain design
- Heat-treated load plates and internal components
