These hoists include all the premium features with an added safety mechanism. Overload protection prevents operation if the load exceeds safe limits. They are available in models from 1 to 20 tons. Zinc phosphate chains and steel frames ensure long-lasting performance. Each hoist undergoes a 1.5x rated capacity test. Removable hooks offer flexibility during use. Headroom is minimized for tight installations. Chain fall lengths vary from 10 to 30 feet. The product meets ANSI/ASME, OSHA, and CE standards. These hoists are ideal for precision lifting where safety is paramount.
Premium Chain Block Hoists with Overload Protection
Mobile Nav
The SUMNER Material Lifts Premium Chain Block Hoist with Overload Protection offers safe, reliable lifting in critical environments. Its built-in overload clutch prevents lifting beyond rated capacity, protecting both operator and equipment. With capacities from 1 to 20 tons (907 – 18,144 kg) and chain lengths up to 30 ft / 9.14 m, it features a corrosion-resistant zinc phosphate chain and durable steel components. Compact and low-headroom, it’s ideal for utilities, marine, and industrial use, meeting ANSI/ASME, OSHA, and CE standards.
SPECIFICATIONS
• Built-in overload protection prevents over-capacity lifts
• Rated from 1 – 20 tons / 907 – 18,144 kg
• Up to 30 ft / 9.14 m lifting height
• Corrosion-resistant zinc phosphate chain
• Designed for safety-critical lifting applications
• Hardened steel sheave rollers
• Compact, low-headroom configuration
• ANSI/ASME, OSHA, CE compliant
• 1.5x tested for durability and safety
• Perfect for energy, marine, and regulated industries
| Part No. | Stock # | Decription | Lifting Weight Capacity |
| 787448 | PCB100C10WO | 1 ton chain hoist with 10 ft chain fall w/ overload protection | 1 ton / 2,000 lbs / 907 kg |
| 787449 | PCB100C15WO | 1 ton chain hoist with 15 ft chain fall w/ overload protection | 1 ton / 2,000 lbs / 907 kg |
| 787450 | PCB100C20WO | 1 ton chain hoist with 20 ft chain fall w/ overload protection | 1 ton / 2,000 lbs / 907 kg |
| 787451 | PCB100C30WO | 1 ton chain hoist with 30 ft chain fall w/ overload protection | 1 ton / 2,000 lbs / 907 kg |
| 787452 | PCB150C10WO | 11/2 ton chain hoist with 10 ft chain fall w/ overload protection | 1-½ ton / 3,000 lbs / 1,361 kg |
| 787453 | PCB150C15WO | 11/2 ton chain hoist with 15 ft chain fall w/ overload protection | 1-½ ton / 3,000 lbs / 1,361 kg |
| 787454 | PCB150C20WO | 11/2 ton chain hoist with 20 ft chain fall w/ overload protection | 1-½ ton / 3,000 lbs / 1,361 kg |
| 787455 | PCB150C30WO | 11/2 ton chain hoist with 30 ft chain fall w/ overload protection | 1-½ ton / 3,000 lbs / 1,361 kg |
| 787456 | PCB200C10WO | 2 ton chain hoist with 10 ft chain fall w/ overload protection | 2 ton / 4,000 lbs / 1,814 kg |
| 787457 | PCB200C15WO | 2 ton chain hoist with 15 ft chain fall w/ overload protection | 2 ton / 4,000 lbs / 1,814 kg |
| 787458 | PCB200C20WO | 2 ton chain hoist with 20 ft chain fall w/ overload protection | 2 ton / 4,000 lbs / 1,814 kg |
| 787459 | PCB200c30WO | 2 ton chain hoist with 30 ft chain fall w/ overload protection | 2 ton / 4,000 lbs / 1,814 kg |
| 787460 | PCB300c10WO | 3 ton chain hoist with 10 ft chain fall w/ overload protection | 3 ton / 6,000 lbs / 2,722 kg |
| 787461 | PCB300c15WO | 3 ton chain hoist with 15 ft chain fall w/ overload protection | 3 ton / 6,000 lbs / 2,722 kg |
| 787462 | PCB300c20WO | 3 ton chain hoist with 20 ft chain fall w/ overload protection | 3 ton / 6,000 lbs / 2,722 kg |
| 787463 | PCB300c30WO | 3 ton chain hoist with 30 ft chain fall w/ overload protection | 3 ton / 6,000 lbs / 2,722 kg |
| 787464 | PCB500c10WO | 5 ton chain hoist with 10 ft chain fall w/ overload protection | 5 ton / 10,000 lbs / 4,536 kg |
| 787465 | PCB500c15WO | 5 ton chain hoist with 15 ft chain fall w/ overload protection | 5 ton / 10,000 lbs / 4,536 kg |
| 787466 | PCB500C20WO | 5 ton chain hoist with 20 ft chain fall w/ overload protection | 5 ton / 10,000 lbs / 4,536 kg |
| 787467 | PCB500C30WO | 5 ton chain hoist with 30 ft chain fall w/ overload protection | 5 ton / 10,000 lbs / 4,536 kg |
| 787468 | PCB1KC10WO | 10 ton chain hoist with 10 ft chain fall w/ overload protection | 10 ton / 20,000 lbs / 9,072 kg |
| 787469 | PCB1KC15WO | 10 ton chain hoist with 15 ft chain fall w/ overload protection | 10 ton / 20,000 lbs / 9,072 kg |
| 787470 | PCB1KC20WO | 10 ton chain hoist with 20 ft chain fall w/ overload protection | 10 ton / 20,000 lbs / 9,072 kg |
| 787471 | PCB1KC30WO | 10 ton chain hoist with 30 ft chain fall w/ overload protection | 10 ton / 20,000 lbs / 9,072 kg |
| 787472 | Pcb1.5kc10WO | 15 ton chain hoist with 10 ft chain fall w/ overload protection | 15 ton / 30,000 lbs / 13,608 kg |
| 787473 | Pcb1.5kc15WO | 15 ton chain hoist with 15 ft chain fall w/ overload protection | 15 ton / 30,000 lbs / 13,608 kg |
| 787474 | Pcb1.5kc20WO | 15 ton chain hoist with 20 ft chain fall w/ overload protection | 15 ton / 30,000 lbs / 13,608 kg |
| 787475 | PCB1.5KC30WO | 15 ton chain hoist with 30 ft chain fall w/ overload protection | 15 ton / 30,000 lbs / 13,608 kg |
| 787476 | PCB2KC10WO | 20 ton chain hoist with 10 ft chain fall w/ overload protection | 20 ton / 40,000 lbs / 18,144 kg |
| 787477 | PCB2KC15WO | 20 ton chain hoist with 15 ft chain fall w/ overload protection | 20 ton / 40,000 lbs / 18,144 kg |
| 787478 | PCB2KC20WO | 20 ton chain hoist with 20 ft chain fall w/ overload protection | 20 ton / 40,000 lbs / 18,144 kg |
| 787479 | PCB2KC30WO | 20 ton chain hoist with 30 ft chain fall w/ overload protection | 20 ton / 40,000 lbs / 18,144 kg |
